DETAILS
NTA855-C360S10 Cummins engine assy for SHANTUI SD32 bulldozer
Packing: Standard export wooden case.
TNW Machinery and Equipment Co., LimitedPacking: Standard export wooden case.
Parts are available, but not limited to, for following models:
SHANTUI Bulldozers: SD08, SD13, SD16, SD22, SD23, SD32, and SD42.
KOMATSU Excavators: PC130-7, PC200-7, PC200-8, PC220-7, PC220-8, PC240-7, PC240-8, PC270-7, PC270-8, PC300-7, PC300-8, PC360-7, PC400-7, PC400-8, PC450-7, PC450-8.
KOMATSU Bulldozers: D53A-17, D65A-8, D85A-18, D85A-21, D155A-2.
KOMATSU Wheel loaders: WA250-1, WA320-3, WA380-3, WA420-3, WA470-3, WA500-3.
CUMMINS Engines: 4BT, 6BT, 6CT, 6L, 4ISDE, 6ISDE, 4ISBE, 6ISBE, 6ISLE, NT855, N14, M11, L10, K19, K38.
SANY Excavators: SY65C, SY75C, SY135C, SY195C, SY215C, SY225C, SY365H, SY465H, etc.
SANY Trucks: SRT55, SRT95.
TEREX Trucks: TR50, TR60, TR100, etc.
LIUGONG: CLG8128H, CLG862, CLG862-LNG, CLG835, ZL50CN, 856IV, ZL50D, CLG842IV, CLG816A, CLG812C, CLG833, CLG856H, LG823D, CLG836-I, ZL50CNX, ZL50CN-LNG, CLG825C, CLG820C-I, CLG820C, CLG818C, CLG816C, CLG842III, CLG842, CLG877III, CLG855N, CLG899III, ZLG30G, ZLG40G, ZLG50G, CLG852, ZL50CX, ZL40B, ZL30E, ZL100C, CLG856, CLG899, CLG816, CLG836, CLG855, CLG856III, CLG888III, CLG888, ZL50C.
| SD32 TORQUE CONVERTER AND TRANSMISSION PARTS | |
| 175-20-30000 | universal joint ass’y |
| 175-20-11140 | fitting, grease |
| 175-20-11110 | bearing |
| 175-20-11120 | spider |
| 175-20-11130 | plate |
| 01010-51260 | bolt |
| 01602-21236 | washer, spring |
| 01010-51260 | bolt |
| 01602-21236 | washer, spring |
| 175-13-21007 | Torque converter ass’y |
| 195-13-13114 | housing |
| 07042-20415 | plug |
| 175-13-23290 | plug |
| 07005-01612 | gasket |
| 175-13-23220 | cover |
| 175-13-23231 | gasket |
| 01010-51225 | bolt |
| 01602-21236 | washer, spring |
| 07044-13620 | plug, magnetic |
| 07002-43634 | O-ring |
| 175-13-24111 | gear |
| 06030-05206 | bearing |
| 04064-03015 | washer, spring |
| 09607-05080 | plate name |
| 04418-03060 | screw, tapping |
| 04530-11628 | bolt, eye |
| 195-13-13400 | filter ass’y |
| 195-13-13410 | cover |
| 07000-62070 | O-ring |
| 195-13-13420 | filter |
| 195-13-13430 | stud |
| 01641-20608 | washer |
| 01590-10607 | nut |
| 04050-11212 | pin, cotter |
| 01010-51230 | bolt |
| 01643-31232 | washer |
| 175-13-23500 | scavenging pump ass’y |
| 175-13-23510 | drive gear ass’y |
| 175-13-23580 | gear |
| 175-13-23610 | shaft |
| 175-13-23520 | driven gear ass’y |
| 175-13-23580 | gear |
| 175-13-23620 | shaft |
| 138-13-23530 | case, pump |
| 01190-01011 | helisert |
| 175-13-23540 | cover |
| 04020-00820 | pin |
| 01010-50835 | bolt |
| 01602-20825 | washer, spring |
| 01641-20812 | washer |
| 07000-62115 | O-ring |
| 01010-51235 | bolt |
| 01602-21236 | washer, spring |
| 01641-21223 | washer |
| 195-13-16100 | relief valve ass’y |
| 195-13-16110 | body, valve |
| 195-13-16450 | plug |
| 07002-43634 | O-ring |
| 195-13-16120 | spool, valve |
| 195-13-16131 | spring |
| 195-13-16141 | plug |
| 07002-43634 | O-ring |
| 07042-20108 | plug, taper |
| 07020-00613 | fitting, grease |
| 07000-62018 | O-ring |
| 07000-63045 | O-ring |
| 01010-51290 | bolt |
| 01602-21236 | washer, spring |
| 175-13-26401 | regulator valve ass’y |
| 175-13-26410 | body, valve |
| 195-13-16450 | plug |
| 07002-43634 | O-ring |
| 195-13-16420 | spool, valve |
| 195-13-16430 | spring |
| 195-13-16141 | plug |
| 07002-43634 | O-ring |
| 07042-20108 | plug |
| 07000-62018 | O-ring |
| 07000-63045 | O-ring |
| 01010-51295 | bolt |
| 01602-21236 | washer, spring |
| 175-11-11112 | gasket , torque to engine |
| 01010-51240 | bolt |
| 01602-21236 | washer, spring |
| 175-13-21124 | pump |
| 175-13-21141 | gear |
| 01643-31032 | washer |
| 01010-51035 | bolt |
| 175-13-21160 | bearing |
| 01010-61035 | bolt |
| 01602-21030 | washer, spring |
| 01643-31032 | washer |
| 07040-11007 | plug |
| 175-13-21213 | case |
| 175-13-21220 | gear |
| 01010-61230 | bolt |
| 01643-21232 | washer |
| 175-13-21253 | pilot |
| 195-13-11261 | gasket, lock |
| 01010-51230 | bolt |
| 175-13-21513 | turbine ass’y |
| 175-13-21552 | turbine |
| 175-13-21532 | boss |
| 175-13-21540 | plate |
| 195-13-11550 | rivet |
| 175-13-21641 | coupling ass’y |
| 175-13-21662 | coupling |
| 175-13-11671 | cover |
| 07020-00613 | fitting grease |
| 175-13-21240 | bearing |
| 175-13-21654 | shaft |
| 175-13-21692 | ring, snap |
| 175-13-21712 | gasket, lock |
| 175-13-11810 | bolt, reamer |
| 178-13-11720 | ring, seal |
| 06040-06313 | bearing |
| 175-13-21770 | washer |
| 04064-06525 | ring, snap |
| 175-13-21750 | seat |
| 07000-35055 | O-ring |
| 175-13-22313 | stator |
| 175-13-22122 | race |
| 01010-51030 | bolt |
| 01643-31032 | washer |
| 175-13-22524 | shaft |
| 04064-08530 | ring, snap |
| 195-13-12711 | ring, seal |
| 07000-65190 | O-ring |
| 01010-51235 | bolt |
| 01602-21236 | washer, spring |
| 175-13-22721 | cover |
| 175-13-22730 | seal |
| 07011-10080 | seal, oil |
| 07000-65135 | O-ring |
| 01010-51230 | bolt |
| 01010-21236 | washer, spring |
| 175-15-00226 | Transmission ass’y |
| 175-15-41111 | case |
| 01010-51240 | bolt |
| 01602-01236 | washer, spring |
| 04020-01228 | pin, dowel |
| 175-15-41121 | gasket |
| 04530-02438 | bolt, eye |
| 09608-005080 | plate, name |
| 04418-03060 | screw, tapping |
| 175-15-00216 | Torque flow transmission ass’y |
| 175-15-00260 | housing ass’y |
| 175-15-41160 | housing |
| 145-14-11320 | plug |
| 175-15-41172 | plate |
| 145-14-11320 | plug |
| 175-15-41189 | housing |
| 145-14-11320 | plug |
| 04020-01228 | pin, dowel |
| 175-15-41192 | bolt |
| 175-15-41292 | bolt |
| 145-14-11570 | washer |
| 09231-01430 | sleeve |
| 175-15-41211 | cage |
| 195-15-11230 | plug |
| 07042-00211 | plug, taper |
| 07018-11805 | ring, seal |
| 06000-06016 | bearing, ring |
| 195-15-11240 | spacer |
| 170-14-22140 | ring, snap |
| 07012-10100 | seal, oil |
| 07000-05290 | O-ring |
| 01010-51235 | bolt |
| 01602-01236 | washer, spring |
| 175-15-42112 | shaft |
| 175-15-42122 | gear, sun, follower |
| 195-15-12141 | spacer |
| 06000-06924 | bearing |
| 130-09-16780 | ring, snap |
| 175-15-42151 | coupling, universal |
| 07000-05055 | O-ring |
| 175-15-12160 | plate, coupling |
| 01010-31230 | bolt |
| 04081-05512 | plate, lock |
| 175-15-42311 | cage, bearing |
| 01010-31230 | bolt |
| 01602-01236 | washer, spring |
| 175-15-42322 | carrier, planetary |
| 175-15-42451 | gear |
| 175-15-42471 | gear |
| 175-15-42512 | shaft |
| 175-15-42532 | shaft |
| 04260-00635 | ball |
| 09232-05125 | bearing |
| 09233-05125 | washer |
| 175-15-42610 | gear, ring |
| 175-15-42620 | gear, ring |
| 175-15-42632 | gear, ring, 3rd |
| 175-15-12715 | disk, clutch |
| 175-15-42721 | plate, clutch |
| 175-15-42860 | piston |
| 175-15-12750 | ring, seal |
| 175-15-12820 | ring, seal |
| 175-15-42870 | piston |
| 195-15-12740 | ring, seal |
| 175-15-42780 | spring |
| 145-14-12810 | spring |
| 145-14-12760 | pin |
| 175-15-12780 | pin |
| 175-15-42670 | ring, snap |
| 175-15-42920 | plate |
| 175-15-42880 | spring, washer tape |
| 178-15-11130 | housing |
| 234-15-12780 | screw |
| 175-15-41140 | plate |
| 145-14-11320 | plug |
| 175-14-41150 | housing |
| 145-14-11320 | plug |
| 175-15-31210 | pin, dowel |
| 04020-01228 | pin |
| 07000-63022 | O-ring |
| 175-15-41310 | collar |
| 04020-00616 | pin |
| 01010-31425 | bolt |
| 01602-01442 | washer, spring |
| 06042-00212 | bearing |
| 04064-06020 | ring, snap |
| 175-15-42131 | gear |
| 04064-08530 | ring, snap |
| 175-15-42213 | shaft |
| 145-14-11320 | plug |
| 175-15-42850 | ring, seal |
| 06000-06924 | bearing |
| 130-09-16780 | ring, snap |
| 04070-00130 | ring, snap |
| 175-15-42180 | spring, rim |
| 234-21-12180 | nut |
| 175-15-42220 | pin |
| 234-21-12190 | plate |
| 234-21-12210 | plate, lock |
| 01010-30816 | bolt |
| 175-15-42340 | plate |
| 130-09-15740 | ring, snap |
| 175-15-42364 | carrier, planetary |
| 175-15-42571 | gear, drum |
| 01010-31490 | bolt |
| 01602-01442 | washer, spring |
| 04020-01228 | pin |
| 175-15-42491 | gear |
| 175-15-42552 | shaft |
| 04260-00635 | ball |
| 09232-03838 | bearing |
| 09233-03820 | washer |
| 175-15-42650 | gear, ring |
| 175-15-42412 | housing cylinder |
| 04260-00952 | ball |
| 175-15-42971 | collar valve |
| 234-15-12790 | screw |
| 175-15-42421 | drum |
| 175-15-42430 | O-ring |
| 01010-31230 | bolt |
| 01602-01236 | washer, spring |
| 04020-01228 | pin |
| 175-15-12715 | disk, clutch |
| 175-15-42721 | plate |
| 175-15-12750 | ring, seal |
| 175-15-42870 | piston |
| 195-15-12740 | ring, seal |
| 154-15-12715 | disk, clutch |
| 281-15-12720 | plate |
| 175-15-42740 | piston |
| 175-15-42750 | ring, seal |
| 234-15-11220 | ring, seal |
| 145-14-12790 | spring |
| 175-15-42240 | plate, lock |
| 175-15-42230 | bolt |
| 01582-01210 | nut |
| 175-15-42890 | spring |
| 175-15-43116 | rear housing |
| 07042-20211 | plug, taper |
| 175-15-43152 | case |
| 01010-31240 | bolt |
| 01602-01236 | washer, spring |
| 06000-22211 | bearing |
| 04065-01030 | ring, snap |
| 175-15-43272 | gear |
| 175-15-49340 | bearing |
| 175-15-43270 | bearing |
| 175-15-43232 | gear |
| 178-15-13240 | shaft, pinion |
| 178-15-19350 | bearing |
| 178-15-13140 | cover |
| 178-15-13260 | cage, bearing |
| 01010-31250 | bolt |
| 01602-01236 | washer, spring |
| 178-15-13360 | spacer |
| 178-15-13370 | spacer |
| 178-15-19330 | bearing |
| 178-15-13620 | plate, snap |
| 04081-07012 | plate, lock |
| 01010-31435 | bolt |
| 175-15-05011 | shim ass’y |
| 175-15-05051 | shim ass’y |
| 178-15-00121 | shim ass’y |
| 155-15-00370 | control valve ass’y |
|
SD23 Transmission Gear and Shaft Related Parts |
|||||
|
Part No.
|
Part Name
|
Part No.
|
Part Name
|
Part No.
|
Part Name
|
|
154-15-41002
|
transmission assy
|
154-15-42321
|
carrier
|
154-15-42131
|
shaft
|
|
154-15-42111
|
shaft
|
07043-70108
|
plug
|
07018-11205
|
seal ring
|
|
154-15-42230
|
gear
|
154-15-42420
|
gear
|
06000-06019
|
bearing
|
|
154-15-42160
|
collar
|
561-15-49410
|
bearing
|
04071-00145
|
snap ring
|
|
154-15-42241
|
gear
|
561-15-32590
|
washer
|
154-15-42270
|
hub
|
|
04064-07025
|
snap ring
|
154-15-42521
|
shaft
|
07018-12205
|
seal ring
|
|
06000-06922
|
bearing
|
04260-00635
|
ball
|
144-15-11290
|
seal ring
|
|
06000-06014
|
bearing
|
154-15-42940
|
cover
|
154-15-42210
|
gear
|
|
04065-01104
|
snap ring
|
01010-51030
|
bolt
|
154-15-42150
|
collar
|
|
154-15-42171
|
collar
|
01643-31032
|
washer
|
06000-06922
|
bearing
|
|
154-15-42190
|
coupling
|
154-15-42651
|
gear ring
|
154-15-42220
|
gear
|
|
07000-05055
|
O-ring
|
568-15-12950
|
snap ring
|
04064-09530
|
snap ring
|
|
154-15-42180
|
holder
|
154-15-42630
|
gear ring
|
234-21-12180
|
nut
|
|
01051-51800
|
bolt
|
154-15-42620
|
gear ring
|
175-15-42220
|
pin
|
|
06000-06216
|
bearing
|
175-15-69510
|
snap ring
|
234-21-12190
|
plate
|
|
04701-00140
|
snap ring
|
154-15-42610
|
gear ring
|
234-21-12210
|
plate
|
|
07012-10100
|
seal
|
175-15-12780
|
pin
|
01010-50814
|
bolt
|
|
154-15-41171
|
housing
|
175-15-42880
|
spring
|
154-15-42310
|
carrier
|
|
07043-70312
|
plug
|
23A-15-12960
|
spring
|
154-15-42410
|
gear
|
|
144-15-21191
|
bolt
|
198-15-22810
|
disc
|
154-15-49410
|
bearing
|
|
145-14-11570
|
washer
|
426-15-12720
|
plate
|
569-15-32560
|
thrust washer
|
|
07000-05250
|
O-ring
|
154-15-41140
|
housing
|
154-15-42510
|
shaft
|
|
154-15-42331
|
carrier
|
154-15-42750
|
piston
|
04260-00635
|
ball
|
|
154-15-42440
|
gear
|
175-15-59250
|
seal ring
|
154-15-42930
|
cover
|
|
561-15-49410
|
bearing
|
582-15-19240
|
seal ring
|
04020-00616
|
dowel pin
|
|
561-15-32590
|
washer
|
154-15-41130
|
housing
|
568-15-12950
|
snap ring
|
|
154-15-42530
|
shaft
|
04020-01434
|
dowel pin
|
154-15-41270
|
pin
|
|
04260-00635
|
ball
|
175-15-42880
|
spring
|
||
|
154-15-49510
|
snap ring
|
154-15-41290
|
pin
|
||
|
154-15-49260
|
seal ring
|
421-15-12910
|
spring
|
||
|
175-15-69230
|
seal ring
|
424-15-12710
|
disc
|
||
|
154-15-42641
|
gear ring
|
424-15-12720
|
plate
|
||
|
175-15-12780
|
pin
|
175-15-62730
|
piston
|
||
|
175-15-42880
|
spring
|
195-15-49210
|
seal ring
|
||
|
234-15-15230
|
spring
|
113-15-29250
|
seal ring
|
||
|
198-15-22810
|
disc
|
154-15-42840
|
housing
|
||
|
426-15-12720
|
plate
|
566-15-41320
|
plug
|
||
|
426-15-12750
|
piston
|
195-15-49240
|
seal ring
|
||
|
426-15-19220
|
seal ring
|
04020-01228
|
dowel pin
|
||
|
426-15-19210
|
seal ring
|
04020-00616
|
dowel pin
|
||
|
154-15-41160
|
housing
|
01010-51235
|
bolt
|
||
|
145-14-11320
|
plug
|
01643-31232
|
washer
|
||
|
04020-01434
|
dowel pin
|
175-15-62830
|
collar
|
||
|
175-15-62750
|
piston
|
125-15-29510
|
ring
|
||
|
175-15-59250
|
seal ring
|
154-15-43130
|
cage
|
||
|
426-15-19210
|
seal ring
|
175-15-11230
|
plug
|
||
|
234-15-15230
|
spring
|
154-15-49210
|
seal ring
|
||
|
154-15-41150
|
housing
|
19M-15-19260
|
seal ring
|
||
|
569-15-41310
|
sleeve
|
01010-61435
|
bolt
|
||
|
07000-73022
|
O-ring
|
01643-31445
|
washer
|
||
|
175-15-62760
|
piston
|
||||
|
155-15-12811
|
seal ring
|
||||
|
582-15-19240
|
seal ring
|
||||
|
SHANTUI PUMPS AND VALVES
|
|||
|
Item
|
Part Name
|
Part No.
|
Model No.
|
|
1
|
Steering Valve
|
16Y-76-22000
|
SD16
|
|
2
|
Control Valve Ass'y
|
16Y-75-10000
|
SD16
|
|
3
|
Lubrication Valve Ass'y
|
16Y-75-20000
|
TY160,SD16
|
|
4
|
Safety Valve
|
16Y-76-23000 |
TY160,SD16
|
|
5
|
Valve
|
16Y-11-30000
|
TY160,SD16
|
|
6
|
Hydraulic Control Valve
|
16Y-60-11000
|
TY160,SD16
|
|
7
|
Valve Ass'y
|
16Y-60-05000
|
SD16,SD13
|
|
8
|
Steering Valve Ass'y
|
154-40-00082
|
SD22,SD23,TY230
|
|
9
|
Transmission Valve Ass'y
|
154-15-35000
|
TY220,SD22
|
|
10
|
Blade Lift and Tilt Control Valve Ass'y
|
701-34-11002
|
TY220,SD22
|
|
11
|
Lubrication Valve Ass'y
|
154-15-34000
|
TY220,SD22
|
|
12
|
Main Relief Valve Ass'y
|
701-30-51002
|
TY220,SD22
|
|
13
|
Valve Ass'y
|
154-49-51100
|
SD22
|
|
14
|
Ripper Control Valve Ass'y
|
701-32-27001
|
TY220,SD22
|
|
15
|
Relief Valve Ass'y
|
195-13-16100
|
SD22,SD32
|
|
16
|
Valve Ass'y
|
175-13-26401 |
SD22,TY320,SD32
|
|
17
|
Servo Valve Ass'y for Blade Lift
|
702-12-13001
|
SD22,SD32
|
|
18
|
Servo Valve Ass'y for Blade Tilt and Ripper Control
|
702-12-14000
|
SD22,SD32
|
|
19
|
Universal Joint Ass'y
|
16Y-12-00000
|
SD16
|
|
20
|
Universal Joint Ass'y
|
154-20-10002
|
SD22
|
|
21
|
Universal Joint Ass'y
|
16T-12-00000
|
SD16T
|
|
22
|
Universal Joint Ass'y
|
175-20-30000
|
SD32
|
|
23
|
Pump Ass'y
|
07446-66103
|
SD32,TY320
|
|
24
|
Steering Pump Ass'y
|
07440-72202
|
SD32,TY320
|
|
25
|
Transmission Pump Ass'y
|
07433-71103
|
SD32,TY320
|
|
26
|
Transmission Pump Ass'y
|
07443-71103
|
SD32
|
|
27
|
Pump Ass'y
|
705-51-30190
|
SD23
|
|
28
|
Hydraulic Pump Ass'y
|
07444-66103
|
SD22,TY220
|
|
29
|
Steering Pump Ass'y
|
07436-72202
|
SD22,TY220
|
|
30
|
Transmission Pump Ass'y
|
07432-71203
|
TY220,TY160,SD16
|
|
31
|
Pump Ass'y
|
705-21-32051
|
SD22,SD23
|
|
32
|
Hydraulic Pump Ass'y
|
16Y-61-01000
|
SD16,TY160
|
|
33
|
Steering Pump Ass'y
|
16Y-76-06000
|
SD16,TY160
|
|
34
|
Transmission Oil Pump
|
16Y-75-24000
|
SD16,TY160
|
|
35
|
Pump Ass'y
|
16T-70-10000
|
SD16T,TY160, Komatsu D60
|
|
36
|
Hydraulic Pump Ass'y
|
10Y-61-04000
|
SD13,TY130
|
|
37
|
Steering Oil Pump Ass'y
|
10Y-76-11000
|
SD13,TY130
|
|
38
|
Transmission Pump
|
10Y-75-12000
|
SD13,TY130
|
|
39
|
Scavenging Pump Ass'y
|
175-13-23500
|
SD22,SD23,SD32
|
